flacon030

c'est exactement pour cette raison je n'ai pas choisie le KNX bien que sur le principe cela me plaisait beaucoup Mais devoir tirer un câble bus sans rien oublier ou sans faire des modifications au fil de temps, ce n'est pas si simple Il faut vraiment tous prévoir a l'avance et ne rien oublier Perso je suis 100% Z-wave avec 95 capteurs et tous mes besoins sont remplies par ces capteurs Tous les modules z-wave me donne pleines satisfaction or mis deux ou trois qui ne fonctionne pas toujours de façon fiable comme les serrures danalock qui ne s'actionne pas de temps a autre ou les relais 40A AEON Labs en fonction de leur firmware qui perdent parfois la remonté de consommation. Par contre je n'ai jamais eu de problèmes avec les modules fibaro. Seul quelques équipements son en IP comme l'onduleur, le ohmpilot, l'ecodevice, la station netatmo, l'ondilo eco, le melcloud pour la clim, mes TV Sony, ampli Yamaha et denon, les cameras Pour cette partie la un bon réseau est indispensable Bref si je devais refaire une configuration je pense que je ferais encore la même chose Je resterais en Z-wave

pour cette fin d'année petit point sur mon installation - du coté informatique je suis en full unifi avec 5 cameras en G5 un UDM PRO SE avec une free box ultra ou j'ai des débits de 3.75 Gbps dans les deux sens j'ai mis en place un US-XG-6PoE pour avoir un réseau en 10G en SFP+ entre mon mac mini M2 pro et mon NAS qnap 855X plus un switch USW-16-Poe et 3 switch USW-Lite-8-PoE et 3 bornes U6 LR - Du cote de l'onduleur je suis a présent avec un GEN24 plus en triphasé accouplé avec 12 panneaux de 420Wc, et avec 16,6KW/h de batterie -Coté domotique j'ai toujours ma fidèle HC3 pour tous les scenario et la puissance de gea avec HA (qui fonctionne dans une VM sur mon qnap) pour les modules que la HC3 ne saurais pas gérer et un pont bridge homkite sur HA pour avoir mes commandes vocale avec siri (fini google home et alexa) -pour tous se qui est données tous fonctionne sous grafana a présent dans un dokers sur mon qnap

pour moi pour le moment tous semble OK Mais je n'ai pas de mqtt

Petit recap J'ai réussi a compilé l'ESP32 avec la config yaml ci dessus cela fonctionne avec l'adresse ip de l'ESP32 cela fonctionne avec ESP home sous home assistant je viens d'installer le QA avec le debug activé car il ne fonctionne pour avec la HC3 voici les logs Merci [02.12.2024] [18:21:47] [TRACE] [QA_MITSUBISHI_1077]: [02.12.2024] [18:21:47] [TRACE] [QA_MITSUBISHI_1077]: QuickApp Mitsubishi v2.00 - Initialization - Parent device [02.12.2024] [18:21:47] [TRACE] [QA_MITSUBISHI_1077]: [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: Using tools library v2.30 [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: Using ESPHome library v2.00 [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: Temperature device ID not defined, using internal temperature sensor [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure("tcp", "192.168.1.80", 6053) [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "HomeassistantServiceMap" => field "key" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "HomeassistantServiceMap" => field "value" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ListEntitiesServicesArgument" => field "name" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ListEntitiesServicesArgument" => field "type" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "bool_" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "legacy_int" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "float_" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "string_" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "int_" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "bool_array" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "int_array" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "float_array" ignored [02.12.2024] [18:21:47] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "ExecuteServiceArgument" => field "string_array" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothServiceData" => field "uuid" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothServiceData" => field "legacy_data" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothServiceData" => field "data" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothLERawAdvertisement" => field "address" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothLERawAdvertisement" => field "rssi" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothLERawAdvertisement" => field "address_type" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothLERawAdvertisement" => field "data" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTDescriptor" => field "uuid" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTDescriptor" => field "handle" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTCharacteristic" => field "uuid" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTCharacteristic" => field "handle" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTCharacteristic" => field "properties" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTCharacteristic" => field "descriptors" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTService" => field "uuid" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTService" => field "handle" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "BluetoothGATTService" => field "characteristics" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "VoiceAssistantAudioSettings" => field "noise_suppression_level" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "VoiceAssistantAudioSettings" => field "auto_gain" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "VoiceAssistantAudioSettings" => field "volume_multiplier" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "VoiceAssistantEventData" => field "name" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:configure() option message_id not found for message "VoiceAssistantEventData" => field "value" ignored [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome library v2.00 successfully initialized [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome URL : tcp://192.168.1.80:6053 [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: Refresh interval : 60 seconds [02.12.2024] [18:21:48] [DEBUG] [QA_MITSUBISHI_1077]: Using internal temperature sensor [02.12.2024] [18:21:51] [DEBUG] [QA_MITSUBISHI_1077]: loop(60) [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:setDeviceNotification() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:checkVG() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:setVG() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:iif() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:split() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:deepCompare() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:urlencode() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:distributeViewLayoutItems() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:isNil() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:getSlider() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:getDurationInString() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:searchViewLayoutItem() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:round() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:updateSlider() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:getDeviceNotification() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:saveViewLayout() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:addViewLayoutItem() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:getViewLayoutItemIndex() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:WOL() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:base64() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:isNotNil() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:isNumber() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:createVG() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:deleteVariable() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:removeViewLayoutItem() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:deepFilter() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:getDeviceIdByName() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: Optimize tools:optimize() [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: init(function()) [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:getDeviceInfo(table[2]) [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI("DeviceInfoRequest", {}, "DeviceInfoResponse", true, false, table[2])[02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI() New TCP connection [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:connect(table[2]) [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:connect() connect() success [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI("DeviceInfoRequest", {}, "DeviceInfoResponse", true, false, table[2])[02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI() New ESPHome login [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:login(table[2]) [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI("HelloRequest", {"client_info":"Fibaro HC3-00003815"}, "HelloResponse", true, false, table[2] [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:transmit("HelloRequest", {"client_info":"Fibaro HC3-00003815"}, table[2])[02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:buildPacket("HelloRequest", {"client_info":"Fibaro HC3-00003815"}) [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:buildPacket() message "HelloRequest" => id 1 [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:buildPacket() field name = "client_info" / field type = "string" / field value = "Fibaro HC3-00003815" [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:buildPacket() wire LEN id = 2 => "010" / field id = 1 => "00001" ==//==> tag = Hex "0a" => "00001010" [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:transmit() packet ASCII : .....Fibaro HC3-00003815 [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:transmit() packet HEX : 00 15 01 0a 13 46 69 62 61 72 6f 20 48 43 33 2d 30 30 30 30 33 38 31 35 [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:transmit() write() success [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:receive(table[2] [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:receive() read() success : 22 bytes [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:receive() packet ASCII : ....Bad indicator byte [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:receive() packet HEX : 01 00 13 01 42 61 64 20 69 6e 64 69 63 61 74 6f 72 20 62 79 74 65 [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:fetchResponse("Bad indicator byte") [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:fetchResponse() data size = 22 [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:fetchResponse() message_count = 0 - data_size = 22 - index = 1 [02.12.2024] [18:21:52] [WARNING] [QA_MITSUBISHI_1077]: ESPHome:fetchResponse() Invalid ESPHome packet [02.12.2024] [18:21:52] [ERROR] [QA_MITSUBISHI_1077]: ESPHome:receive() fetchResponse() failed : Invalid ESPHome packet [02.12.2024] [18:21:52] [ERROR] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI() Receive failed : Invalid ESPHome packet [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:nativeAPI() request message "HelloRequest" removed from queue at index1 [02.12.2024] [18:21:52] [ERROR] [QA_MITSUBISHI_1077]: ESPHome:login() HelloRequest error() : Invalid ESPHome packet [02.12.2024] [18:21:52] [DEBUG] [QA_MITSUBISHI_1077]: ESPHome:disconnect() [02.12.2024] [18:21:52] [ERROR] [QA_MITSUBISHI_1077]: Can't get ESPHome device info : Invalid ESPHome packet [02.12.2024] [18:21:52] [TRACE] [QA_MITSUBISHI_1077]: Update label "LabelDebug" to "❌ Invalid ESPHome packet ❌" [02.12.2024] [18:21:52] [WARNING] [QA_MITSUBISHI_1077]: Mitsubishi virtuel / graph is now dead

en tous les cas il semble qu'il se soit remis au travail... Et perso pour le moment la dernière stable semble l’être pour ma par

Merci c'est bon je viens de réussir a le faire fonctionner a nouveau

oui jetait même a 5 minutes mais rien ne se passe.

je reviens au nouvelles le QA fonctionne t'il comme il faut chez vous? Perso je n'ai aucune reaction au niveau du split [17.11.2024] [19:42:10] [TRACE] [QUICKAPP1076]: ----------------------------- [17.11.2024] [19:42:10] [TRACE] [QUICKAPP1076]: Initialisation du QA MelCloud [17.11.2024] [19:42:10] [TRACE] [QUICKAPP1076]: ----------------------------- [17.11.2024] [19:42:10] [DEBUG] [QUICKAPP1076]: [17.11.2024] [19:43:36] [TRACE] [QUICKAPP1076]: onAction: {"actionName":"setThermostatMode","deviceId":1076,"manual":true,"args":["Heat"]}[17.11.2024] [19:43:39] [TRACE] [QUICKAPP1076]: onAction: {"actionName":"setHeatingThermostatSetpoint","deviceId":1076,"manual":true,"args":[20.5]} [17.11.2024] [19:43:44] [TRACE] [QUICKAPP1076]: onAction: {"actionName":"setHeatingThermostatSetpoint","deviceId":1076,"manual":true,"args":[22]}

petite avancé je viens de réussir a compiler l'ESP32 que se soit avec python ou (esphome sous HA en ajoutant un nouvelle ESP32 pour avoir ota: password, api: key) - J'arrive a faire fonctionner la clim sur le connecteur CN105 mais pas sur le CN110 (cela ne m'arrange pas... mais cela fera l'affaire en attendant mieux) - cela ne fonctionne qu'avec l'ESP32 que j'ai acheter sur alixepress mais pas ceux de amazone https://fr.aliexpress.com/item/32858054775.html?spm=a2g0o.order_list.order_list_main.20.246f5e5bDE8bNB&gatewayAdapt=glo2fra - Je pense qu'il faut mettre tx_pin : 16, et rx_pin:17 (a essayer)et non 3 et 4 (j'ai du me tromper j'ai du inverser les fils pour que cela fonctionne donc c'est: tx_pin : 17, et rx_pin:16) - reste a essayer de lancer la mise en place du QA sous HC3 car l’interface web de l'esp32 n'est pas la même, il y a plus d'options Cela ne semble pas fonctionner?? https://forum.hacf.fr/t/piloter-sa-pompe-a-chaleur-mitsubishi-en-local-avec-une-sonde-deportee/8544/101 substitutions: name: clim-emaes friendly_name: clim-emaes esphome: name: ${name} platform: ESP32 board: wemos_d1_mini32 uart: id: HP_UART baud_rate: 2400 tx_pin: 17 rx_pin: 16 external_components: - source: github://echavet/MitsubishiCN105ESPHome ota: - platform: esphome password: "xxxxxxx" wifi: ssid: !secret wifi_ssid password: !secret wifi_password power_save_mode: none manual_ip: static_ip: 192.168.1.xxx gateway: 192.168.1.1 subnet: 255.255.255.0 # Enable fallback hotspot (captive portal) in case wifi connection fails ap: ssid: "${friendly_name} ESP Fallback Hotspot" password: "Killer060+" captive_portal: # Enable Web server. web_server: port: 80 # Enable logging logger: hardware_uart: UART1 level: INFO logs: EVT_SETS : INFO WIFI : INFO MQTT : INFO WRITE_SETTINGS : INFO SETTINGS : INFO STATUS : INFO CN105Climate: WARN CN105: INFO climate: WARN sensor: WARN chkSum : INFO WRITE : WARN READ : WARN Header: INFO Decoder : INFO CONTROL_WANTED_SETTINGS: INFO # level: DEBUG # logs: # EVT_SETS : DEBUG # WIFI : INFO # MQTT : INFO # WRITE_SETTINGS : DEBUG # SETTINGS : DEBUG # STATUS : INFO # CN105Climate: WARN # CN105: DEBUG # climate: WARN # sensor: WARN # chkSum : INFO # WRITE : WARN # READ : WARN # Header: INFO # Decoder : DEBUG # CONTROL_WANTED_SETTINGS: DEBUG # Sync time with Home Assistant. time: - platform: homeassistant id: homeassistant_time # Sensors with general information. sensor: # Uptime sensor. - platform: uptime name: ${name} Uptime # WiFi Signal sensor. - platform: wifi_signal name: ${name} WiFi Signal update_interval: 60s # Text sensors with general information. text_sensor: # Expose ESPHome version as sensor. - platform: version name: ${name} ESPHome Version # Expose WiFi information as sensors. - platform: wifi_info ip_address: name: ${name} IP ssid: name: ${name} SSID bssid: name: ${name} BSSID # Create a button to restart the unit from HomeAssistant. Rarely needed, but can be handy. button: - platform: restart name: "Restart ${friendly_name}" climate: - platform: cn105 id: hp name: "${friendly_name}" icon: mdi:heat-pump update_interval: 4s # Defaut 500ms visual: min_temperature: 15 max_temperature: 31 temperature_step: target_temperature: 0.5 current_temperature: 0.1 compressor_frequency_sensor: name: ${name} Compressor Frequency vertical_vane_select: name: ${name} Vertical Vane horizontal_vane_select: name: ${name} Horizontal Vane isee_sensor: name: ISEE Sensor # The remote_temperature_timeout setting allows the unit to revert back to the internal temperature measurement # if it does not receive an update in the specified time range (highly recommended if using remote temperature updates) remote_temperature_timeout: 30min # debounce_delay adds a small delay to the command processing to account for some HomeAssistant buttons that may send # repeat commands too quickly. A shorter value creates a more responsive UI, a longer value protects against repeat commands debounce_delay : 500ms # Enable Home Assistant API api: encryption: key: "xxxxxxxxx" services: # Ajouter une valeur de température comme si c'était un capteur externe # Créer une automatisation qui envoie la température d'un capteur # chaque fois qu'une nouvelle valeur est détectée - service: set_remote_temperature_clim_rdc variables: temperature: float then: # Select between the C version and the F version # Uncomment just ONE of the below lines. The top receives the temperature value in C, # the bottom receives the value in F, converting to C here. - lambda: 'id(hp).set_remote_temperature(temperature);' # - lambda: 'id(hp).set_remote_temperature((temperature - 32.0) * (5.0 / 9.0));' # Revenir à l'utilisation du capteur interne - service: use_internal_temperature_clim_rdc then: - lambda: 'id(hp).set_remote_temperature(0);'

Pour info j'ai aussi installer esphome sous home assistant, et j'ai toujours le même message d'erreur

Merci je continue de mon coté pour essayer de trouver une solution Car en l'état actuel a mon avis ce QA ne peut plus être mis en place

bon j'ai downgrader esphome en version esphome 2023.7.1 je n'ai pas réussi a aller plus bas https://pypi.org/project/esphome/2023.7.1/ Mais cela ne fonctionne toujours pas j'ai aussi essayer de dowgrader wheel en 0.38.4 https://pypi.org/project/wheel/0.45.0/#history Je commence a en avoir marre... Si une âme charitable pouvait programmer mes deux ESP32 je lui en serais reconnaissant Je peut lui envoyer les deux cartes et je peut remunerer le travail si il le faut Merci d'avance au volontaire

déjà cela me rassure, cela ne viens pas de moi reste a voir comment downgrader esphome ou attendre une nouvelle version car l'hiver arrive et il me reste deux split a convertir en ESP32

J'ai essayé sous unbuntu 22.03 et windows 11 et c'est toujours le même résultat flacon030@ubuntu-2204:~/Documents/ESPHome$ esphome run mitsubishi-emaes.yaml INFO ESPHome 2024.10.3 INFO Reading configuration mitsubishi-emaes.yaml... INFO Generating C++ source... INFO Core config, version or integrations changed, cleaning build files... INFO Compiling app... Processing mitsubishi-emaes (board: wemos_d1_mini32; framework: arduino; platform: platformio/espressif32@5.4.0) ---------------------------------------------------------------------------------------------------- Library Manager: Installing esphome/AsyncTCP-esphome @ 2.1.4 INFO Installing esphome/AsyncTCP-esphome @ 2.1.4 Unpacking [####################################] 100% Library Manager: AsyncTCP-esphome@2.1.4 has been installed! INFO AsyncTCP-esphome@2.1.4 has been installed! Library Manager: Installing esphome/ESPAsyncWebServer-esphome @ 3.2.2 INFO Installing esphome/ESPAsyncWebServer-esphome @ 3.2.2 Unpacking [####################################] 100% Library Manager: ESPAsyncWebServer-esphome@3.2.2 has been installed! INFO ESPAsyncWebServer-esphome@3.2.2 has been installed! Library Manager: Resolving dependencies... INFO Resolving dependencies... Library Manager: Installing bblanchon/ArduinoJson @ 6.18.5 INFO Installing bblanchon/ArduinoJson @ 6.18.5 Downloading [####################################] 100% Unpacking [####################################] 100% Library Manager: ArduinoJson@6.18.5 has been installed! INFO ArduinoJson@6.18.5 has been installed! Library Manager: Installing git+https://github.com/SwiCago/HeatPump#5d1e146771d2f458907a855bf9d5d4b9bf5ff033 INFO Installing git+https://github.com/SwiCago/HeatPump#5d1e146771d2f458907a855bf9d5d4b9bf5ff033 git version 2.34.1 Cloning into '/home/flacon030/.platformio/.cache/tmp/pkg-installing-454rino4'... remote: Enumerating objects: 1242, done. remote: Counting objects: 100% (111/111), done. remote: Compressing objects: 100% (75/75), done. remote: Total 1242 (delta 52), reused 82 (delta 36), pack-reused 1131 (from 1) Receiving objects: 100% (1242/1242), 460.21 KiB | 4.11 MiB/s, done. Resolving deltas: 100% (618/618), done. HEAD is now at 5d1e146 Merge pull request #209 from dzungpv/master Library Manager: HeatPump@1.0.0+sha.5d1e146 has been installed! INFO HeatPump@1.0.0+sha.5d1e146 has been installed! HARDWARE: ESP32 240MHz, 320KB RAM, 4MB Flash - toolchain-xtensa-esp32 @ 8.4.0+2021r2-patch5 Dependency Graph |-- AsyncTCP-esphome @ 2.1.4 |-- WiFi @ 2.0.0 |-- FS @ 2.0.0 |-- Update @ 2.0.0 |-- ESPAsyncWebServer-esphome @ 3.2.2 |-- DNSServer @ 2.0.0 |-- ESPmDNS @ 2.0.0 |-- ArduinoJson @ 6.18.5 |-- HeatPump @ 1.0.0+sha.5d1e146 Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/api_connection.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/api_frame_helper.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/api_pb2.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/api_pb2_service.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/api_server.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/list_entities.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/proto.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/subscribe_state.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/api/user_services.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/captive_portal/captive_portal.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/climate/climate.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/climate/climate_mode.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/climate/climate_traits.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/esp32/core.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/esp32/gpio.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/esp32/preferences.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/json/json_util.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/logger/logger.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/logger/logger_esp32.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/logger/logger_esp8266.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/logger/logger_host.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/logger/logger_libretiny.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/logger/logger_rp2040.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mdns/mdns_component.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mdns/mdns_esp32.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mdns/mdns_esp8266.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mdns/mdns_host.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mdns/mdns_libretiny.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mdns/mdns_rp2040.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/mitsubishi_heatpump/espmhp.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/network/util.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/select/select.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/select/select_call.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/select/select_traits.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/socket/bsd_sockets_impl.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/socket/lwip_raw_tcp_impl.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/socket/lwip_sockets_impl.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/socket/socket.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/web_server/list_entities.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/web_server/web_server.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/web_server/web_server_v1.cpp.o Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/web_server_base/web_server_base.cpp.o In file included from src/esphome.h:26, from src/esphome/components/mitsubishi_heatpump/espmhp.h:20, from src/esphome/components/mitsubishi_heatpump/espmhp.cpp:21: src/esphome/components/mitsubishi_heatpump/espmhp.h:182:14: error: 'optional' in namespace 'std' does not name a template type std::optional<std::chrono::duration<long long, std::ratio<60>>> remote_operating_timeout_; ^~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:182:9: note: 'std::optional' is only available from C++17 onwards std::optional<std::chrono::duration<long long, std::ratio<60>>> remote_operating_timeout_; ^~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:183:14: error: 'optional' in namespace 'std' does not name a template type std::optional<std::chrono::duration<long long, std::ratio<60>>> remote_idle_timeout_; ^~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:183:9: note: 'std::optional' is only available from C++17 onwards std::optional<std::chrono::duration<long long, std::ratio<60>>> remote_idle_timeout_; ^~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:184:14: error: 'optional' in namespace 'std' does not name a template type std::optional<std::chrono::duration<long long, std::ratio<60>>> remote_ping_timeout_; ^~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:184:9: note: 'std::optional' is only available from C++17 onwards std::optional<std::chrono::duration<long long, std::ratio<60>>> remote_ping_timeout_; ^~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:185:14: error: 'optional' in namespace 'std' does not name a template type std::optional<std::chrono::time_point<std::chrono::steady_clock>> last_remote_temperature_sensor_update_; ^~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:185:9: note: 'std::optional' is only available from C++17 onwards std::optional<std::chrono::time_point<std::chrono::steady_clock>> last_remote_temperature_sensor_update_; ^~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:186:14: error: 'optional' in namespace 'std' does not name a template type std::optional<std::chrono::time_point<std::chrono::steady_clock>> last_ping_request_; ^~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.h:186:9: note: 'std::optional' is only available from C++17 onwards std::optional<std::chrono::time_point<std::chrono::steady_clock>> last_ping_request_; ^~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'virtual void MitsubishiHeatPump::control(const esphome::climate::ClimateCall&)': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:252:9: error: 'last_remote_temperature_sensor_update_' was not declared in this scope if (last_remote_temperature_sensor_update_.has_value()) { ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:252:9: note: suggested alternative: 'enforce_remote_temperature_sensor_timeout' if (last_remote_temperature_sensor_update_.has_value()) { ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ enforce_remote_temperature_sensor_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'void MitsubishiHeatPump::set_remote_temperature(float)': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:625:9: error: 'last_remote_temperature_sensor_update_' was not declared in this scope last_remote_temperature_sensor_update_ = ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/wifi/wifi_component.cpp.o src/esphome/components/mitsubishi_heatpump/espmhp.cpp:625:9: note: suggested alternative: 'enforce_remote_temperature_sensor_timeout' last_remote_temperature_sensor_update_ = ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ enforce_remote_temperature_sensor_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp:628:9: error: 'last_remote_temperature_sensor_update_' was not declared in this scope last_remote_temperature_sensor_update_.reset(); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:628:9: note: suggested alternative: 'enforce_remote_temperature_sensor_timeout' last_remote_temperature_sensor_update_.reset(); ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ enforce_remote_temperature_sensor_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'void MitsubishiHeatPump::ping()': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:636:5: error: 'last_ping_request_' was not declared in this scope last_ping_request_ = std::chrono::steady_clock::now(); ^~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'void MitsubishiHeatPump::set_remote_operating_timeout_minutes(int)': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:641:5: error: 'remote_operating_timeout_' was not declared in this scope remote_operating_timeout_ = std::chrono::minutes(minutes); ^~~~~~~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:641:5: note: suggested alternative: 'set_remote_operating_timeout_minutes' remote_operating_timeout_ = std::chrono::minutes(minutes); ^~~~~~~~~~~~~~~~~~~~~~~~~ set_remote_operating_timeout_minutes src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'void MitsubishiHeatPump::set_remote_idle_timeout_minutes(int)': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:646:5: error: 'remote_idle_timeout_' was not declared in this scope remote_idle_timeout_ = std::chrono::minutes(minutes); ^~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:646:5: note: suggested alternative: 'set_timeout' remote_idle_timeout_ = std::chrono::minutes(minutes); ^~~~~~~~~~~~~~~~~~~~ set_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'void MitsubishiHeatPump::set_remote_ping_timeout_minutes(int)': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:651:5: error: 'remote_ping_timeout_' was not declared in this scope remote_ping_timeout_ = std::chrono::minutes(minutes); ^~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:651:5: note: suggested alternative: 'set_timeout' remote_ping_timeout_ = std::chrono::minutes(minutes); ^~~~~~~~~~~~~~~~~~~~ set_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp: In member function 'void MitsubishiHeatPump::enforce_remote_temperature_sensor_timeout()': src/esphome/components/mitsubishi_heatpump/espmhp.cpp:656:9: error: 'remote_ping_timeout_' was not declared in this scope if (remote_ping_timeout_.has_value() && last_ping_request_.has_value()) { ^~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:656:9: note: suggested alternative: 'set_timeout' if (remote_ping_timeout_.has_value() && last_ping_request_.has_value()) { ^~~~~~~~~~~~~~~~~~~~ set_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp:656:45: error: 'last_ping_request_' was not declared in this scope if (remote_ping_timeout_.has_value() && last_ping_request_.has_value()) { ^~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:669:28: error: 'remote_operating_timeout_' was not declared in this scope this->operating_ ? remote_operating_timeout_ : remote_idle_timeout_; ^~~~~~~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:669:28: note: suggested alternative: 'set_remote_operating_timeout_minutes' this->operating_ ? remote_operating_timeout_ : remote_idle_timeout_; ^~~~~~~~~~~~~~~~~~~~~~~~~ set_remote_operating_timeout_minutes src/esphome/components/mitsubishi_heatpump/espmhp.cpp:669:56: error: 'remote_idle_timeout_' was not declared in this scope this->operating_ ? remote_operating_timeout_ : remote_idle_timeout_; ^~~~~~~~~~~~~~~~~~~~ Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/wifi/wifi_component_esp32_arduino.cpp.o src/esphome/components/mitsubishi_heatpump/espmhp.cpp:669:56: note: suggested alternative: 'set_timeout' this->operating_ ? remote_operating_timeout_ : remote_idle_timeout_; ^~~~~~~~~~~~~~~~~~~~ set_timeout src/esphome/components/mitsubishi_heatpump/espmhp.cpp:671:13: error: 'last_remote_temperature_sensor_update_' was not declared in this scope last_remote_temperature_sensor_update_.has_value()) { ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ src/esphome/components/mitsubishi_heatpump/espmhp.cpp:671:13: note: suggested alternative: 'enforce_remote_temperature_sensor_timeout' last_remote_temperature_sensor_update_.has_value()) { ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ enforce_remote_temperature_sensor_timeout Compiling .pioenvs/mitsubishi-emaes/src/esphome/components/wifi/wifi_component_esp8266.cpp.o *** [.pioenvs/mitsubishi-emaes/src/esphome/components/mitsubishi_heatpump/espmhp.cpp.o] Error 1 =================================== [FAILED] Took 23.06 seconds =================================== flacon030@ubuntu-2204:~/Documents/ESPHome$ j'ai fait un essai sous unbuntu 22.04 et sous windows 11 et c'est toujours la même chose.

oui j'ai supprimé la ligne ota mais cela donne toujours le même résultat
